| AFUE Rating | : | 83 % |
| BTU Rating | : | 250 MBtu/hr Input, 209 MBtu/hr Heating |
| Chimney/Breeching/Vent Size | : | 8 in ID x 20 ft H |
| Connection Type | : | 1/2 in Gas, 2 to 3 in NPT Supply, 2 to 2-1/2 in NPT Return |
| Dimensions | : | 33-3/4 in H x 29-3/4 in W x 27-5/8 in D |
| Fuel Type | : | Natural Gas |
| Ignition Type | : | Intermittent Electronic |
| Material | : | Cast-Iron |
| Model | : | EG-65 |
| Mounting Type | : | Floor |
| Net BTU Rating | : | 157 MBtu/hr |
| Series | : | 5 Series |
| Vent Type | : | Atmospheric (Chimney) |
Weil-McLain® Gas Fired Water Boiler, 5 Series, Model: EG-65, 83 % AFUE, 250 MBtu/hr Input, 209 MBtu/hr Heating BTU, 1/2 in Gas, 2 to 3 in NPT Supply, 2 to 2-1/2 in NPT Return Connection, Natural Gas Fuel, Atmospheric (Chimney) Vent, Chimney/Breeching/Vent Size: 8 in ID x 20 ft H, Intermittent Electronic Ignition, Net BTU Rating: 157 MBtu/hr, Floor Mounting, Cast-Iron, Dimensions: 33-3/4 in H x 29-3/4 in W x 27-5/8 in D
- Factory assembled section block
- Insulated extended jacket
- Horizontal to vertical draft hood
- Combination gas valve for 24 V
- Non-linting pilot burner
- Stainless steel burners
- Electrical junction box
- Spill switch
- Rollout thermal fuse element
- 40 V-A transformer
- Syphon
- 15 lb/sq-in ASME pressure relief valve and boiler sections tested for 15 lb/sq-in working pressure
- Steam pressure gauge
- High limit pressure control
- Intermittent electronic ignition system with Weil-McLain UCM universal ignition control module
- Low water cut-off electrode type
- Gauge cocks and glass
- Easy access to controls for convenient servicing
- 1-1/2 in forced water supply and return, 3 in steam riser and header, 1-1/2 in steam equalizer
