Amperage | : | 40-amp non-inductive @ 120, 208 or 240 VAC |
Maximum hp | : | 2 hp @ 120, 208 or 240 VAC |
Operating temperate Range | : | -35 °F to 175 °F (-37°C to 79°C) |
Overall case Dimensions | : | 7.697"H x 4.4"W x 3.8" D |
Pilot Duty | : | 690 VA @ 120, 208, or 240 VAC |
Pressure terminated | : | Yes |
Switching | : | 1 NO/ 2 NC |
Time initiated temperature | : | Yes |
Time initiated/Time terminated | : | No |
Voltage | : | 120 |
- Adjustable defrost initiation frequency: one to six times per day
- Heavy-duty synchronous motor
- Adjustable defrost cycle duration: 4 to 110 minutes in two-minute increments
- Contact arrangements: electric heat, hot gas, or off cycle defrost available
- Heavy-duty steel case with electrical knockouts in the side, back and bottom
- Voltage 120
- Switching 1 NO/2 NC
- Time initiated/time terminated No
- Time initiated temperature Yes
- Pressure terminated Yes
- Amperage 40-amp non-inductive No.64 120, 208 or 240VAC
- Maximum hp: 2 hp No.64 120, 208 or 240VAC
- Pilot duty 690 VA No.64 120, 208, or 240VAC
- Operating temperate range -35 deg F to 175 deg F (-37 deg C to 79 deg C)
- Overall case dimensions 7.697 in H x 4.4 in W x 3.8 in D
