| Additional Information | : | RAC Classification, 2023 Version, Inverter R-410A HP Type, WindFree Geo Design, Motion Detect Sensor, Wi-Fi Feature |
| Amperage Rating | : | 1/4.2/6.3 A Cooling, 1.1/3.8/9 A Heating |
| Color | : | White |
| Compressor Type | : | BLDC Rotary |
| Connection Type | : | Flared |
| Cooling BTU Rating | : | 12000 Btu/hr |
| Cooling CFM Rating | : | 251 to 427 cfm |
| Cooling Operating Temperature | : | 0 to 115 deg F |
| Drive Type | : | Inverter |
| EER Rating | : | 13.5 |
| Frequency Rating | : | 60 Hz |
| Fuse Rating | : | 20 A |
| HSPF Rating | : | 10.5 |
| Heating BTU Rating | : | 12000 Btu/hr |
| Heating CFM Rating | : | 1589 cfm Condenser, 286 to 463 cfm Evaporator |
| Heating Operating Temperature | : | -22 to 75 deg F |
| Heating Sound Level | : | 46 dBA |
| Material | : | Steel |
| Model | : | AR12CSDACWKXCV |
| Number of Fan Speeds | : | 3 |
| Overall Height | : | 21-9/16 in |
| Overall Length | : | 11-1/4 in |
| Overall Width | : | 31-1/8 in |
| Phase | : | 1 ph |
| Power Rating | : | 40 W Condenser, 27 W Evaporator |
| Refrigerant Type | : | R-410A |
| SEER Rating | : | 23 |
| Voltage Rating | : | 208 - 230 V |
Samsung's exclusive WindFree™* cooling technology provides users with a cool indoor climate without the discomfort of direct cold airflow. It's an advantage no other system can match.
Samsung WindFree™ 3.0 Split System Outdoor Unit, Model: AR12CSDACWKXCV, 208 - 230 V, 1/4.2/6.3 A Cooling, 1.1/3.8/9 A Heating, 40 W Condenser, 27 W Evaporator, 60 Hz, 1 ph Phase, 3 Fan Speeds, 12000 Btu/hr Heating, 12000 Btu/hr Cooling, 1589 cfm Condenser, 286 to 463 cfm Evaporator Heating CFM Rating, 251 to 427 cfm Cooling CFM Rating, 13.5 EER Rating, 23 SEER, 10.5 HSPF, Flared Connection, BLDC Rotary Compressor, R-410A Refrigerant, 20 A Fuse Rating, Inverter Drive, 46 dBA Heating Sound Level, Steel, White, -22 to 75 deg F Heating Operating Temperature, 0 to 115 deg F Cooling Operating Temperature, 11-1/4 in Overall Length, 31-1/8 in Overall Width, 21-9/16 in Overall Height, Additional Information: RAC Classification, 2023 Version, Inverter R-410A HP Type, WindFree Geo Design, Motion Detect Sensor, Wi-Fi Feature
- The Samsung Max Heat system shall provide 100% heating capacity at -4 degF outdoor temperature and high heating capacity at -22 degF outdoor temperature
- The outdoor unit shall include a base pan heater as standard to ensure optimal defrost cycle water drainage
- The indoor unit shall feature WindFree™* mode. In cooling mode, as room temperature nears set temperature, the unit will close its louver and will disperse air into the space through thousands of micro-holes on the front of the indoor unit preventing cold air drafts on occupants
- The indoor unit shall have Wi-Fi capability as standard
- Outdoor unit shall provide 208/230V power to indoor unit via 14 AWG X 3 interconnect power cable
- Built-in motion sensor for airflow direction control and energy saving operation
