| Additional Information | : | 8-7/16 in D Dimensions, R-410A Refrigerant |
| Amperage Rating | : | 5 A |
| BTU Rating | : | 15000 Btu/hr |
| CFM Rating | : | 399 cfm, 424 cfm, 466 cfm, 491 cfm, 533 cfm, 554 cfm, 579 cfm, 600 cfm |
| Connection Type | : | 1/4 in Flared High Side, 1/2 in Flared Low Side, 11/16 in OD Condensate |
| EER Rating | : | 14 |
| Frequency Rating | : | 60 Hz |
| Fuse Rating | : | 20 A |
| HSPF Rating | : | 10.8 |
| Mounting Type | : | Wall |
| Number of Fan Speeds | : | 3 |
| Overall Height | : | 11-3/4 in |
| Overall Width | : | 41-9/16 in |
| Phase | : | 1 ph |
| Power Rating | : | 27 W, 40 W |
| SEER Rating | : | 21.5 |
| Sound Level | : | 21 dB, 41 dB |
| Temperature Rating | : | 50 to 86 deg F Cooling, 61 to 90 deg F Heating |
| Voltage Rating | : | 208 to 230 V |
Samsung exclusive WindFree™ cooling technology provides users with a cool indoor climate without the discomfort of direct cold airflow. It's an advantage no other system can match.
Samsung WindFree™ Evaporator Indoor Split System, 208 to 230 V, 5 A, 27 W, 40 W, 60 Hz, 1 ph, 3 Number of Fan Speeds, 15000 Btu/hr, 399 cfm, 424 cfm, 466 cfm, 491 cfm, 533 cfm, 554 cfm, 579 cfm, 600 cfm Rating, 14 EER, 21.5 SEER, HSPF: 10.8, 1/4 in Flared High Side, 1/2 in Flared Low Side, 11/16 in OD Condensate Connection Type, 20 A Fuse, 21 dB, 41 dB, Wall Mount, 50 to 86 deg F Cooling, 61 to 90 deg F Heating, 41-9/16 in Overall Width, 11-3/4 in Overall Height, Additional Information: 8-7/16 in D Dimensions, R-410A Refrigerant
- The indoor unit shall feature WindFree™ mode
- In cooling mode, as room temperature nears set temperature, the unit will close its louver and will disperse air into the space through thousands of micro holes on the front of the indoor unit preventing cold air drafts on occupants
- The indoor unit shall have Wi-Fi capability as standard
- Built-in motion sensor for airflow direction control and energy saving operation
- Indoor unit chassis shall be UL 94-V0 with a galvanized steel mounting bracket
- The indoor unit shall have easy access to wire, pipe and drain connections via access panel on the bottom of the unit for simple installation and service
- The outdoor unit shall be galvanized steel with a baked on powder-coated finish for durability
- The heat exchangers shall be mechanically bonded fin to copper tube
- The compressor shall be hermetically sealed, inverter controlled, BLDC rotary
- Refrigerant flow shall be controlled by an electronic expansion valve at the outdoor unit
- The indoor fan shall be a single, anti-bacterial cross-flow type
- Three-fan speed settings and auto setting
- Automatic (motorized) vertical swing (up/down) and horizontal swing (left/right) louvers
- The system shall have a built-in Wi-Fi adapter as standard to allow control and monitoring using the Samsung SmartThings app (Android, iOS)
- Dual set temperature support when connected to MWR-WG00UN advanced wired controller
- The indoor unit shall have a simple connection for overflow detection devices or any other normally closed contact for simple unit shutdown
- The indoor unit shall ship with a wireless controller, holder and batteries
- Samsung central control compatible (MIM-R10UN accessory required)
