| Additional Information | : | RAC Classification, 2015 Version, AR3000 Design |
| Amperage Rating | : | 2.6/3.5/5.7 A Cooling, 2.4/3.9/5.9 A Heating |
| Color | : | Twilight White |
| Compressor Type | : | BLDC Rotary |
| Connection Type | : | Flared |
| Cooling BTU Rating | : | 9000 Btu/hr |
| Cooling Operating Temperature | : | 14 to 115 deg F |
| Drive Type | : | Inverter |
| EER Rating | : | 13 |
| Finish | : | Galvanized/Powder-Coated |
| Frequency Rating | : | 60 Hz |
| Fuse Rating | : | 15 A |
| HSPF Rating | : | 9 |
| Heating BTU Rating | : | 9000 Btu/hr |
| Heating CFM Rating | : | 1024 cfm Condenser, 210 to 390 cfm Evaporator |
| Heating Operating Temperature | : | -5 to 75 deg F |
| Heating Sound Level | : | 53 dBA |
| Material | : | Steel |
| Model Number | : | AR09 |
| Model | : | AR09 |
| Mounting Type | : | Wall |
| Number of Fan Speeds | : | 3 |
| Overall Height | : | 22 in |
| Overall Length | : | 10-1/16 in |
| Overall Width | : | 29-13/16 in |
| Phase | : | 1 ph |
| Power Rating | : | 0.45 kW Cooling, 0.42 kW Heating |
| Refrigerant Type | : | R-410A |
| SEER Rating | : | 20 |
| Voltage Rating | : | 208 - 230 V |
Samsung Novus Single-Zone Split System Outdoor Unit, Model: AR09, 208 - 230 V, 2.6/3.5/5.7 A Cooling, 2.4/3.9/5.9 A Heating, 0.45 kW Cooling, 0.42 kW Heating, 60 Hz, 1 ph Phase, 3 Fan Speeds, 9000 Btu/hr Heating, 9000 Btu/hr Cooling, 1024 cfm Condenser, 210 to 390 cfm Evaporator Heating CFM Rating, 13 EER Rating, 20 SEER, 9 HSPF, Flared Connection, BLDC Rotary Compressor, R-410A Refrigerant, 15 A Fuse Rating, Inverter Drive, 53 dBA Heating Sound Level, Wall Mounting, Steel, Finish: Galvanized/Powder-Coated, Twilight White, -5 to 75 deg F Heating Operating Temperature, 14 to 115 deg F Cooling Operating Temperature, 10-1/16 in Overall Length, 29-13/16 in Overall Width, 22 in Overall Height, Additional Information: RAC Classification, 2015 Version, AR3000 Design
- Outdoor unit shall provide 120V power to indoor unit via 14 AWG X 5 interconnect power cable (4 wire + ground)
- Electro-static, washable, main filter as standard
- The heat exchanger shall be mechanically bonded fin to copper tube
- The compressor shall be hermetically sealed, inverter controlled, BLDC Rotary
- Refrigerant flow shall be controlled by electronic expansion valve at outdoor unit
- Automatic (motorized) vertical (up and down) swing louver (1)
