| CFM Rating | : | 262 to 888 cfm |
| Compressor Type | : | Inverter Driven, Twin BLDC Rotary |
| Configuration | : | Multi-Position |
| Connection Size | : | 3/4 in |
| Connection Type | : | FNPT |
| Cooling Capacity | : | 24000 Btu/hr |
| Dimensions | : | 43 in H x 17-1/2 in W x 21 in D |
| EER Rating | : | 11 |
| Finish | : | Galvanized/Powder-Coated |
| Frequency Rating | : | 60 Hz |
| HP Rating | : | 1/3 hp |
| Heating Capacity | : | 27000 Btu/hr |
| Material | : | Steel |
| Motor Type | : | BLDC with Axial Type (2) Fan |
| Phase | : | 1 ph |
| Pressure Rating | : | 0.2 in-WC |
| SEER Rating | : | 19.5 |
| Sound Level | : | 35 dBA, 38 dBA, 41 dBA |
| Temperature Rating | : | 61 to 90 deg F Cooling, <=80 deg F Heating |
| Voltage Rating | : | 208 - 230 V |
Samsung Air Handling Unit, 24000 Btu/hr Cooling Capacity, 27000 Btu/hr Heating, 208 - 230 V, 1/3 hp, 60 Hz, 1 ph Phase, Inverter Driven, Twin BLDC Rotary Compressor, 262 to 888 cfm, Multi-Position, 11 EER Rating, 19.5 SEER, FNPT Connection, 35 dBA, 38 dBA, 41 dBA Sound Level, 3/4 in Connection, BLDC with Axial Type (2) Fan Motor, 0.2 in-WC, Steel, Finish: Galvanized/Powder-Coated, 61 to 90 deg F Cooling, <=80 deg F Heating, 43 in H x 17-1/2 in W x 21 in D
- Auto-restart after power loss
- The indoor unit shall be capable of being field convertible to downflow configuration with optional downflow conversion kit
- The outdoor unit shall have a snow accumulation prevention option setting to prevent snow drifting against an idle outdoor unit
- The indoor and outdoor units shall have a removable EEPROM that stores system programming information, unit name, and other data
- The outdoor unit shall have a night time quiet mode option to reduce operating sound during the night (automatic or manual activation with dry contact signal)
- The pipe connections at the outdoor unit shall be internal allowing pipes to inter the chassis through the front, right side, bottom, or back
- Air handler has an air leakage of no more than 2 percent of the design air flow rate when tested in accordance with ASHRAE 193
- The outdoor unit shall supply power to indoor unit via 14 AWG X 3 power wire when optional heat kits are not installed. If VHK-***A supplemental heat kits are installed, power to the heat kits must be provided from a dedicated circuit with proper overcurrent protection per NEC (refer to VHK-***A supporting documents for heat kit electrical data)
