| Additional Information | : | 72 in L Capillary |
| Differential Temperature | : | 3 to 20 deg F |
| Enclosure Type | : | NEMA 1, IP44 |
| Material | : | Steel |
| Operating Temperature | : | 55 deg F |
| Series | : | O Series |
| Suitable For Use With | : | Self-Contained Refrigerators, Freezers, Coolers and Walk-In Units |
| Switch Type | : | SPST |
| Voltage Rating | : | 24 VAC |
The Ranco® wide range O Series temperature controls provide a wide selection of controls customized to allow users exact adjustments within manufacturers limits. The Ranco O Series features heavy-duty plated steel frames, non-conductive covers with front-located captive cover screws, raised screw terminals for fully accessible wiring and large easy-to-read scales. Recognizing the need for flexibility in design of refrigeration equipment, these controls offer a wide selection for such products as self-contained refrigerators, freezers, coolers, walk-in units and refrigeration display cases.
Robertshaw® Medium Temperature Control, O Series, 24 VAC, SPST Switch, 3 to 20 deg F Differential Temperature, NEMA 1, IP44 Enclosure, 55 deg F Operating Temperature, Steel, For Use With: Self-Contained Refrigerators, Freezers, Coolers and Walk-In Units, Additional Information: 72 in L Capillary
- Maximum adjustment accuracy with seven revolution range adjustment screws
- NEMA 1 enclosure with non-conductive cover
- Universal mounting and compact design
- Laser welded bellows for extended life
- 10X setting sensitivity of most other wide range controls (O60 Series only)
- Gas-filled, non-position-sensitive bulb (O60 Series only)
