| Amperage Rating | : | 0.3 A |
| BTU Rating | : | 12000 Btu/hr |
| CFM Rating | : | 390 cfm |
| Connection Type | : | Flared |
| Dehumidification | : | 2.8 pt/hr |
| Dimensions | : | 10-1/4 in H x 32-1/2 in W x 10-13/16 in D |
| Frequency Rating | : | 60 Hz |
| Mounting Type | : | Wall |
| Phase | : | 1 ph |
| Power Rating | : | 27 W |
| Refrigerant Type | : | R-410A |
| Series | : | FJM Series |
| Sound Level | : | 39 dBA |
| Temperature Rating | : | 80 deg F |
| Vent, Ducted or Ductless | : | Ductless |
| Voltage Rating | : | 208 to 230 V |
Quietside® Mini-Split Air Conditioner, Series: FJM Series, 208 to 230 V, 0.3 A, 27 W, 60 Hz, 1 ph, 12000 Btu/hr, 390 cfm CFM Rating, Flared, R-410A, Ductless Vent, Ducted or Ductless, 39 dBA, 2.8 pt/hr Dehumidification, Wall Mount, 80 deg F, 10-1/4 in H x 32-1/2 in W x 10-13/16 in D
- Triangle design to provide optimal airflow in and out of the unit
- Refrigerant pipes, drain pipe, high voltage and low-voltage shall be accessible from the bottom of the unit to provide simplified installation and service
- Refrigerant and drain pipe direction can be applied to exit the right, left, bottom or back sides of the indoor unit
- The drain outlet hose can connect to the left (standard) or right side of the drain pain to provide flexibility during installation
- High voltage terminal block temperature sensor to disable unit in the event overheating of power connection
- The indoor unit shall be powered by the outdoor unit
- HIPS chassis certified to UL94 V0 with galvanized steel mounting bracket
- The heat exchanger shall be mechanically bonded fin to copper tube
- Single anti-bacterial, crossflow indoor fan
- Three-speed fan settings and auto setting
- Control signal shall be a DDC-type signal
- Interconnect control wire between outdoor and indoor units shall be 16 AWG x two-shielded
- Controls shall integrate with a BMS system
- The system shall integrate with the Samsung controls solution
