| Amperage Rating | : | 7.5 A at 120 VAC |
| Connection Type | : | NPT |
| Dimensions | : | 5-5/16 in H x 6-5/8 in W x 6-7/16 in D |
| Enclosure Type | : | NEMA 1 |
| Frequency Rating | : | 50/60 Hz |
| Humidity Rating | : | 85 % |
| Model | : | 751P-MT-120 |
| Pilot Duty Rating | : | 125 VA |
| Power Rating | : | 3 VA |
| Pressure Rating | : | 160 psi Water, 15 psi Steam |
| Reset Type | : | Manual |
| Sensitivity | : | 20000 Ohm |
| Series | : | 751P Series |
| Temperature Rating | : | 32 to 120 deg F |
| Thread Size | : | 3/4 in |
| VA Rating | : | 3 VA |
| Voltage Rating | : | 120 VAC |
The Series 751P/752P probe type LWCOs provide protection against low water conditions for commercial and industrial applications. These controls are fully CSD-1 compliant and are primarily used as LWCOs on hot water heating boilers.
McDonnell & Miller Low Water Cut-Off, 751P Series, Model: 751P-MT-120, 7.5 A at 120 VAC, 120 VAC, 50/60 Hz, VA Rating: 3 VA, 3 VA, Manual Reset, 3/4 in Thread, NPT Connection, 160 psi Water, 15 psi Steam, NEMA 1 Enclosure, 125 VA Pilot Duty, 20000 Ohm Sensitivity, 85 % Humidity Rating, 32 to 120 deg F, 5-5/16 in H x 6-5/8 in W x 6-7/16 in D
- Green LED indicates power on
- Red LED indicating low water condition
- Test button
- No lock out with loss of power if probe is in water
- Self-cleaning probe
